1-Channel, 315MHz, Miniature RF Receiver with Transistor Ground Output

SK-910RAVQ

1-Channel, 315MHz, Miniature RF Receiver with Transistor Ground Output

This mini RF receiver is compatible with both code hopping and fixed-code 315MHz ENFORCER transmitters (see page 4 of the manual for a list of compatible transmitters). It can be used for a variety of applications, such as allowing the same transmitter to open/close a gate and open/close a garage door. The receiver comes in one- or two-channel versions. Each channel can learn the codes of up to 15 different transmitter buttons.

  • product_icon
  • product_icon
  • Small size: 33/16“x29/16“x3/4” (80 x 65 x 19 mm)
  • Control garage doors, etc.
  • Four programmable relay output modes: 4-second momentary, 1-second momentary, toggle, and validity outputs
  • Flexible operating voltage: 3~13.8 VCC
  • Compatible with all 315MHz ENFORCER transmitters, including both fixed-code and code-hopping (CODEBUMPTM)
  • 433MHz (433.92MHz) available
  • LED Indicates RF reception, learn mode entered, transmitter learned, and memory cleared
  • Mode switches for easy transmitter learning
Operating frequency315MHz*
CertificationsFCC
Memory capacity15 transmitter button codes per channel
Operating voltage3~13.8 VDC
Range†Up to 500ft (150m)
Current DrawStandby: 5mA@12VDC
Active: 15mA@12VDC
OutputNumber: 1
Relay: Transistor GND 5A@12VDC
Modes: Programmable 4-sec. momentary (default), 1-sec. momentary, toggle (ON/OFF), or validity
ConnectorsTerminal block, screw terminals
Operating temperature-40°~167° F (-40°~75° C)
Dimensions3-3/16″ x 2-9/16″ x 3/4″ (80 x 65 x 19 mm)

*433.92MHz available by special order only. Contact SECO-LARM for details.
†Operating range will vary greatly depending on the installation and operating environment.
