- Sensing range up to 65 feet (20m)
- 4 selectable frequencies to reduce interference
- Flexible power supply, 12~24 VDC, 12~20 VAC
- Small size for a less conspicuous installation
- Simple installation
- Signal strength indicator for easier alignment
- Built-in IR signal secondary processing technology to filter out lighting disturbances
- LED indicators for power, signal strength, and alarm trigger
- Mounting hardware included
- IP55 Weatherproof
| Type | Photobeam |
| No. of beams | 1 |
| No. of beam frequencies | 4 |
| Detection method | Beam completely blocked |
| Sensing range | 65′ (20m) |
| Response time | 50ms |
| Operating voltage | 12~24 VDC, 12~20 VAC |
| Current draw (max.) | Transmitter: 15mA@12VDC Receiver: 65mA@12VDC |
| Outputs | Number: 1 Type: Selectable NO/NC (default, N.C.) Rating: 3A@24VDC |
| Alarm time range | ≥ 2s |
| Light source | Infrared LED, 940nm |
| LED Indicators | Power: Green (transmitter only) Alarm: Red (receiver only) |
| Beam strength indicators | Weak: Blue – slow flashing = signal, faster flashing = stronger, then off (Receiver) Good: Green – slow flashing = good, faster = better, steady ON = optimal (Receiver) |
| Connectors | Screw terminals |
| IP Rating | IP55 Weatherproof |
| Operating humidity | Up to 95%, non-condensing |
| Operating temperature | −22°~158° F (−30°~70° C) |
| Dimensions (both units) | 1-3/4″x3-3/4″x1-1/4″ (45x95x32 mm) |
