- Connect to the outside of an alarm bell box for external high intensity notification
- Fully epoxied weatherproof (IP66) and vibration-resistant design for external or internal use
- Up to 100,000 hours of continuous use
- 19 Built-in programmable flash patterns
- Up to 15 units can be synchronized to flash simultaneously or alternately
- Multi-voltage input: 10~30VDC
- Non-volatile memory recalls last flash pattern used at power-up
- Surface mounting or flush mounting
| Housing Shape | Rectangular |
| # of LEDs | 4 High-intensity 1W LEDs |
| Max. Current Draw | 560mA@12VDC, 300mA@24VDC |
| Operating Voltage | 10~30VDC |
| Electrical Protection | Reverse polarity protection |
| Operating Life | Rated 100,000 hours (>11 years) |
| # of Flash Patterns | 19 (Programmable) |
| Synchronization | Sync or alternate up to 15 units |
| IP Rating | Weatherproof IP66 |
| Operating Temperature | -22°~150° F (-30°~65° C) |
| Weight | 5-oz (142g) |
| Dimensions | 4-1/2″ x 1-1/4″ x 1-3/16″ (122 x 31 x 30 mm) |
