- Talk with visitors and unlock doors or gates via the monitor
- Handheld monitor’s rechargeable battery allows convenient communication with visitors while moving around the premises
- Wide 33/8” monitor screen for enhanced viewing
- Connect up to two additional monitors (sold separately)
- Includes a kickstand and charging base for the monitor
- Egress input allows the door phone to be connected with a Request-to-Exit Plate or other egress device
- 9~16 VAC/VDC Operation – connects to most doorbell circuits
- Adjustable lens for a wide variety of viewing angles
- Camera’s built-in PIR sensor takes photos of approaching visitors
- Up to 100 images can be stored in memory
- Camera has built-in LEDs for nighttime operation
- Camera is IP55 rated for outdoor use
- Tamper switch triggers alarm if camera is removed from its base
- Four programmable doorbell tones
| Type | Color Camera |
| Chip | CMOS |
| Resolution | 480 TV lines |
| Lens | 2mm |
| Viewing Angle | 170º |
| Operating Voltage | 9~16 VAC/5~16 VDC |
| Relock Delay | 1~6 s |
| Relay Output | 3A@250VAC/30VDC max. |
| Current Draw | Active- [email protected], Standby- [email protected] |
| Battery Life | Active- 4.4 Hours, Standby- 366 Hours (15 days) |
| PIR Detection Range | 9′ (3m) |
| PIR Detection Angle | 138º |
| Dimensions | 5-11/16″ x 3-1/8″ x 1-15/16″ (144 x 80 x 50 mm) with bracket |
| Weight | 4.3-oz (122g) |
| Operating Temperature | 14º~122º F (-10º~50º C) |
| Display | 3-3/8″ (86mm) TFT |
| Operating Voltage | 5VDC (adapter), 3.7VDC (Battery) |
| Current Draw | Active- [email protected], Standby- [email protected] |
| Battery Life | Active- 4.4 Hours, Standby-220 Hours (9 days) |
| Operating Frequency | 2410.875~2471.625MHz |
| RF Power | 120mW |
| Dimensions | 5″ x 3-3/8″ x 7/8″ (127 x 85 x 22 mm) |
| Weight | 3.9-oz (110g) |
| Operating Temperature | 32º~104º F (-0º~40º C) |
