- Auto-adjusting operation
- Up to 1,000 possible user codes (000~999)
- Up to 50 (01~50) possible temporary visitor codes, which can be programmed for one-time or limited-time use (1~99 hours)
- Form C relay, 1A@30VDC max. can be programmed to activate for up to 99,999 seconds (nearly 28 hours)
- Tamper output N.C. Dry contact, 50mA@24VDC max.
- Mounts to a standard single-gang back box (surface-mount back box included)
- All features are programmed directly from the keypad with no need for an external programmer
- EEPROM Memory protects programmed information in case of power loss
- Egress input lets users exit the premises without keying in the code
- Data I/O terminal for split-series setup providing added security
- Expansion port for future optional features
- Always-on backlit keypad
| Operating Voltage | 12~24 VDC/VAC |
| Current Draw | Standby: 15mA Keypress: 30mA Output 1 active: 55mA Total (max.): 90mA |
| Outputs | Output 1, Form C: 1A@30VDC Tamper:50mA@24VDC |
| Egress Inputs | N.O. ground |
| Operating Humidity | 5~95% Non-condensing |
| Operating Temperature | -4°~158° F (-20°~70° C) |
| Dimensions (including back box) | 4-5/8″x2-7/8″x1-15/16″ (117x73x49 mm) |
| Weight | 6-oz (170 g) |
