| Operating voltage | 12~24 VAC/VDC |
| Current Draw | 120mA@12VDC |
| Relay type | Form C dry contact, 3A@24VDC |
| Override button | Switching capacity: 3A@24VDC
Mechanical life: 500,000 cycles |
| Response time | 10ms |
| LEDs | Standby: Red
Triggered: Green |
| Output duration | Adjustable, 0.5~30 sec., toggle, or as long as sensor is triggered |
| Sensing range | Adjustable, 2-3/8″~8″ (6-20 cm) |
| Destructive attack level | Level I |
| Line security | Level I |
| Endurance level | Level IV |
| Standby power | Level I |
| Operating Temperature | -4°~131° F (-20°~55° C) |
| Dimensions | 4-1/2″ x 2-3/4″ x 1-5/16″ (115 x 70 x 33.5 mm) |
| Weight | 3.9-oz (110g) |
