SD-9773-KNEVQ

Surface-Mount Wave-to-Open Sensor with Manual Override Button

The ENFORCER Surface-Mount Wave-to-Open Sensor with Manual Override Button is a full-featured exit plate which uses IR technology to allow egress from a protected area or activate a device with the simple wave of a hand. Since no touch is required, this sensor is suitable for use in hospitals, clinics, labs, cleanrooms (to reduce the risk of contamination), schools, factories, or offices. A manual override allows for operation if the sensor is disabled.

  • product_icon
  • product_icon
  • Adjustable sensor range up to 6″ (15cm)
  • 1A relay, adjustable trigger duration 0.5~30 seconds or toggle
  • LED illuminated sensor area for easy identification
  • Selectable LED colors (turns from red to green or green to red) when sensor is activated
  • Aluminum alloy and ABS plastic housing
  • IP54 Weather-resistant for outdoor use
Operating Voltage 12~24 VDC
Current Draw Standby (red): [email protected] / [email protected] Triggered (green): [email protected] / [email protected] Standby (green):[email protected] / [email protected] Triggered (red): [email protected] / [email protected]
Relay Type SPDT dry contact, [email protected]
IP Rating Weatherproof IP54
Response Time 10ms
LEDs – Standby Red (reversible to green)
LEDs – Triggered Green (reversible to red)
Output Time 0.5~30 s, toggle
Range 1-9/16″~6″ (4~15 cm)
Operating Temperature -4°~131° F (-20°~55° C)
Weight 9.5-oz (270g)
Dimensions 3-1/8″x 4-1/2″x1-1/8″ (80x115x28mm)
